Large Diameter Wind Power Steel-forged Fan Shaft
- HHF
- Jiyuan , Henan
- 2 months
- 200pcs per month
Material for fan shaft : 34CrNi3Mo or according to the customer's requirement
Application of fan shaft : Mainly used in large wind power equipment
Production equipment for shaft : We can do forging , heat treatment , rough machining and final machining by our own factory
Product Introduction
We can produce the fan shaft according to the customer's material and properties .
The fan shaft is mainly used for large wind power equipment , and we can do forging , heat treatment, machining and inpestion by our own factory for forged fan shaft ,
We have specialized in forged fan shaft for 17 years .
As to the after sales for forged fan shaft, from our company side, we would like to provide our best service to you. If any products are with quality problems, we will replace at our expense. For your benefit, we would like to establish a clear quality inspection criterion at the beginning stage of the project.We also have an CRM system to keep work history with all customers to follow up your overall experience with us.
| Stabilizer (non-magnetic stabilizer) specifications | ||||||||||
| Product specification | Working outer diameter OD | Fishing diameter OD | Inner hole ID | Fishing diameter length | Working part length | Total length | Spiral belt width | bevel | Arc | |
| A | B | C | D | F | G | I | a | b | R | |
| in | in | in | in | in | in | in | ° | ° | in | |
| 8 1/2×6 1/2×2 13/16×100 | 8 1/2 | 6 1/2 | 2 13/16 | 30 | 18 | 100 | 2 1/2 | 30 | 30 | 4 |
| 12 1/4×8 1/4×2 13/16×100 | 12 1/4 | 8 1/4 | 2 13/16 | 30 | 18 | 100 | 3 1/2 | 30 | 30 | 4 |
| 12 1/4×8 1/2×2 13/16×100 | 12 1/4 | 8 1/2 | 3 | 30 | 18 | 100 | 3 1/2 | 30 | 30 | 4 |
| 14 3/4×9 1/2×3×100 | 14 3/4 | 9 1/2 | 3 | 30 | 20 | 100 | 3 1/2 | 30 | 30 | 4 |
| 16×9 1/2×3×100 | 16 | 9 1/2 | 3 | 30 | 20 | 100 | 4 | 30 | 30 | 4 |
| 17 1/2×9 1/2×3×100 | 17 1/2 | 9 1/2 | 3 | 30 | 20 | 100 | 4 | 30 | 30 | 4 |
| 22×9 1/2×3×116 | twenty two | 9 1/2 | 3 | 30 | twenty four | 116 | 4 | 45 | 30 | 4 |
| 26×9 1/2×3×116 | 26 | 9 1/2 | 3 | 30 | twenty four | 116 | 4 | 45 | 30 | 4 |
| 28×9 1/2×3×122 | 28 | 9 1/2 | 3 | 30 | 20 | 122 | 4 | 30 | 30 | 4 |
| 32×9 1/2×3×122 | 32 | 9 1/2 | 3 | 30 | 20 | 122 | 5 | 30 | 30 | 5 |
| 36×9 1/2×3×133 | 36 | 9 1/2 | 3 | 30 | 20 | 133 | 5 | 45 | 30 | 5 |
| The size of the stabilizer can also be designed according to user requirements | ||||||||||
About Us
Henan zhongyuan Heavy Forging Co.,Ltd (HHF) which was established in 2006, has gained a great wealth of professional knowledge and technical experience after almost 20 years of heavy forging work.
The factory site is about 150 mu or 100,000 square metres. Here, at the production base, there are three factory-style, large scale drop forging lines (mainly a 10,000-ton hydraulic press is basic), two cutting-edge mold forging production lines as well as some large CNC machining centers, heat treating lines. The laboratory of the national secondary class system is highly equipped too.
The present employees employed by the company total about 500 with over 50 of the researchers working on the development of new materials, methods and technologies.
Our company is the forging supplier of top-tier domestic and global industries. Sectors involved include power generation (wind, water, and thermal), mining machinery industry, shipbuilding, and the construction plant industry. In fact, a number of leading Chinese companies, CITIC HEAVY INDUSTRIES, First Heavy INUSTRIES, Taiyuan HEAVY INUSTRIES, gold wind and Envision ENERGY have been our forges' customers. Besides, some of the company's forging goods have been the choice of major international miners manufacturers like Joy Global, Japan Mining, Hitachi Mining, Komatsu, and Caterpillar.
In line with the specifications of physical and chemical laboratory construction at a National Grade 2 level, we have all the testing facilities installed: tensile test, minus 80 degree Celsius temperature impact test, chemical analysis, metallographic analysis, non-metallic inclusion analysis, gas content analysis, grain size analysis, magnetic induction intensity, non-magnetic induction, magnetic induction gradient, intergranular corrosion testing.
The lab's variety of testing and analysis is mainly responsible for dissecting and understanding the material's performance through the most elemental level. As far as our production process and finished products are concerned, the lab ensures a thorough, data-backed audit. With the help of the industry's standards, we offer a variety of tests from the most basic to the most advanced covering mechanical properties, micro structural characteristics, chemical composition, and special-purpose functionalities and have established a complete quality verification system.
Our Exhibition
Exhibition Participation
HENAN ZHONGYUAN HEAVY FORGING CO., LTD. is proud to announce our participation in MINExpo INTERNATIONAL® 2021.
Event Details:
Show: MINExpo INTERNATIONAL® 2021
Date: September 13-15, 2021
Location: Las Vegas, Nevada, USA
We cordially invite partners, clients, and industry peers to visit our booth for communication and collaboration.
FAQ
1.Wha's your quote time?
Normally, it is up to 3days. We need to understand your requirements and critical dimensions.
2.How is quality controlled?
A. We have a dedicated QA team. B. We shall do one sample run, then a small batch run before mass order.For a sample order.
3.Can I come and visit you?
Yes, of course. We are pleased to welcome you to visit our company and discuss technical details and requirements with our team.
4.What's the production lead time?
Our pruction progress is from forging, rough machining ,Q+T to final machining.Itis usually 45days.
5.what are your payment terms?
We typically ask for 30% down payments to launch production, 70% balance before delivering goods.
